Specification:
Generator Set Technical Specification:
– Generator Set Model: HY-G1200
– Prime Power (kW/kVA): 1200kW/1500kVA
– Standby Power (kW/kVA): 1340kW/1675kVA
– Output Voltage: 400/230V
– Frequency: 50Hz
– Rated Current: 2088A
– Rated Speed (RPM): 1500
– Power Factor: COSΦ=0.8(lagging)
– Fuel Consumption: 206 L/hr
– Battery Rated Capacity (AH): 195AH 4PCS
– Gross Weight: 12821
– Overall Dimension (L*W*H)mm: 5980×2280×2590
Engine Technical Specification:
– Brand: CCEC
– Engine Model: KTA50-GS8
– Cylinder NO.: 16 Cylinders V line
– Prime Power (kW/HP): 1320kW/1795HP
– Standby Power (kW/HP): 1474kW/2004HP
– Rated Speed (RPM): 1500rmp
– Bore*Stroke (mm): 159×159
– Displacement (L): 50.8L
– Exhaust Temperature (℃): 503
– Lubricating Capacity (L): 205L
– Liquid Cooling Capacity (L): 189L
– Fuel Consumption (g/kW.h): 209 g/kW.h
– Oil Consumption (g/kW.h): 0.4 g/kW.h
– Aspiration Method: Turbocharged
– Starting System: Electrical start
– Cooling System: Water cooling
– Governor Type: Electrical Control
Alternator Technical Specification:
– Brand: HY
– Model: HY-G1200
– Rated Capacity (kW/kVA): 1200kW/1450kVA
– Output Voltage: 400/230V
– Enclosure Degree: IP22
– Insulation Degree: H
– Connecting Type: 3PH star, 3PH-DELTA
